Swing Door Operator - DC7000 Low Energy, ADA Compliant

Upgrade your facility with our ADA-Compliant Low Energy Door System from Door Controls USA brought to you by Action Industries. These openers designed to provide safe and accessible entryways for individuals with disabilities. Recognized as the top choice for enhancing accessibility, this system is perfect for healthcare facilities, assisted living centers, retail stores, banks, dormitories, colleges, universities, hotels, schools, and libraries.



Key Features -


• Wide Range of Applications: Ideal for various settings, including healthcare, retail, education, and hospitality.

• Compliance and Safety: Meets ANSI A156.19, A117.1 standards, and the Americans With Disabilities Act of 1990, ensuring accessibility and safety.

• Versatile Installation: Suitable for both new and existing entryways, with quick and hassle-free installation onto pre-existing structures.

• Touchless Activation: Compatible with touchless activation methods, enhancing hygiene and convenience.

• Flexible Door Configurations: Accommodates both butt-hung and center-pivoted door designs.

• Fire and Life-Safety Compliant: Meets necessary fire safety standards for secure use.


Specifications -


• Maximum Door Width: Single Units: 3' to 3'6" (0.914m to 1.067m); Pair Units: 5' to 7' (1.524m to 2.133m)

• Panel Weight: Supports doors up to 200 pounds each (91kg)

• Power Input: 120, 220 VAC, 50-60 Hz, Single Phase; requires 15 amp service, with a current draw of 3.15 amps

• Time Delay: Adjustable from 2 to 30 seconds; complies with ANSI A156.19, requiring a minimum 5-second delay


Enhance the accessibility and safety of your facility with this reliable, code-compliant low energy door system.

Options available -


• Arm Style: Push, Pull, Push/Pull (Double Egress Only)

• Door Type: Single, Pair, Double Egress

• Handing: Left or Right

• Finish: Clear Anodized or Dark Bronze Anodized
