EMX

EMX IRB-EXP Explosion Proof Photoeye

SKU:
IRB-EXP
Write a Review
  • Usually Ships 4 to 7 Business Days
availability:
available
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

EMX’s IRB-EXP explosion proof photo beam has a rugged construction designed for explosive environments. This photo beam is used as a safety, reversing, or opening device in conjunction with automatic operators. The IRB-EXP features a 24° sensing angle for easy alignment and a 115-ft. Operating range. The lens-less design of the IRB-EXP makes it less sensitive to fog, dust, snow, and sunlight, making it a more accurate explosion proof photoeye.

Features:

  • IRB-EXP Explosion Proof Photoeye

  • Thru beam configuration

  • 115 ft. operating range

  • NEMA 4X enclosure

  • Designed to operate in explosive environments

  • Copper free aluminum with epoxy finish

  • NEC Class I, Groups B, C, & D, Class II, Groups E, F, & G CSA certified, CENELEC certified, EExd IIC

  • Potentiometer range adjustment to allow for more precise tuning on site

  • Not affected by shiny surfaces

  • Modulated infrared to reduce the effect of sunlight, fog, rain, dust, and dirt

Product Manual
