LiftMaster

LiftMaster AUXCARD Auxiliary Contacts Option Board

SKU:
AUXCARD
Write a Review
  • Add accessories to commercial door opener and remotely activate relays for them
  • Usually Ships Following Business Day
availability:
available
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

LiftMaster AUXCARD Auxiliary Contacts Option Board | LiftMaster AUXCARD Auxiliary Contacts Option Board is a printed-circuit board additional device for later model LiftMaster Commercial Door Operators. Card supports the use of accessories or auxilliary devices to the LiftMaster Logic board 4 and 5 LiftMaster Commercial Door Operators. Provides additional contacts for accessories. Has added advantage of allowing on/off of these contacts to be controlled by a remote.

 PRODUCT HIGHLIGHTS | SPECS | TECHS

  • Device for allowing the use of accessories on LiftMaster Commercial Door Operators
  • Power for accessories controlled by AUXCARD contacts need external power source
    • Needed power source and strength will depend on the accessory
  • Physcially implants directly to card interface on mother board
  • Wire to terminals using #14 AWG copper wire
  • Maximum contact rating of 10A at 240 Vac | Not applicable for incandescent loads
  • N4 or N4X devices using AUXCARD cannot accommodate remotely turned on/off of relays
  • Contains both NO and NC contacts
  • Relay Functionality Specs
    • Status: While closing:
    • open 2 -1 closed
    • (OPEN or A' relay contacts)
    • open 2 - 3 opened
    • -
    • Status: While closing:
    • open 2 -1 closed
    • (CLOSE or B' relay contacts)
    • open 2 - 3 opened
    • -
    • Status: Operator powered down
    • open 2 - 1 opened
    • open 2 - 3 closed
    • close 2 -1 closed
    • close 2 -3 closed
    • -
    • Status: Operator powered on and door in motion
    • open 2 - 1 opened
    • open 2 - 3 closed
    • close 2 -1 closed
    • close 2 -3 closed
    • -
    • N4 and N4X (NEMA 4 AND NEMA 4X) operators
    • Status: While open or closing
    • Open Terminals not available for Auxiliary use
    • close 2 - 1 opened
    • close 2 - 3 closed
