Sommer
Sommer 2060 EVO+ 3/4 Horsepower Direct Drive Garage Door Opener Model S10256
- SKU:
- S10256
Write a Review
Sommer
Sommer 2060 EVO+ 3/4 Horsepower Direct Drive Garage Door Opener Model S10256
- Usually Ships Following Business Day
- brand-name:
- Sommer
- brand-url:
- /brand/sommer/
- atc-product:
- 104-0265
- availability:
- available
Product Description
The Sommer 2060 EVO+ is a direct drive garage door operator built for long-term reliability and smooth, quiet performance. With only one moving part, the direct drive motor attaches directly to the door, delivering maximum lifting force with minimal maintenance. Designed in Germany, the EVO+ combines precision engineering with advanced security and flexible accessory options for both residential and light commercial applications.
Key Features
- Quiet & Reliable: Direct drive motor with only one moving part for smooth operation
- Motor Power: 600N (3/4 HP) with continuous duty cycle
- SafetySense: Advanced object and force detection with automatic locking counter-pressure
- Encryption: 128-bit rolling code radio technology for secure access
- Flexibility: Standard rail supports 8' doors; optional extensions up to 23'
- Energy Efficient: LED lighting with standby power consumption under 2W
Specifications
- Model: 2060 EVO+
- Motor Power: 600N (3/4 HP)
- Standard Door Height: 7'–8'
- Max Door Height: 23' (with extensions of 21.5" or 43")
- Max Travel Speed: 9.4 in/sec
- Overall Length: 140"
- Standby Power Consumption: < 2W
- Programmable Remote Buttons: Up to 40
- Frequency: 922.5 MHz
- Compatibility: Homelink compatible
- Safety Edge Connection: Yes
- Warning Light Output: 24V DC / 25W
- Shipping Weight: 28.2 lbs
- Shipping Dimensions: 44.5" × 7.5" × 5.0"
Warranty
- Motor: Lifetime
- Parts: 6 years
- Accessories: 2 years
Optional Accessories
- LOCK: Magnetic lock, resists up to 660 lbs of force
- SENSO: Humidity and temperature sensor for ventilation control
- MEMO: Expands memory to 450 transmitter commands
- MOTION SENSOR: Activates LED lighting on garage entry
- BUZZER: Alarm or warning buzzer for break-in or closing alerts
- LUMI EVO+: Additional LED lighting for control unit
- ACCU BATTERY PACK: NiMH backup battery for power outages
- RELAY: Auxiliary relay for garage or courtyard lighting
- SOMLINK: Service module for configuration via smartphone/tablet
- PEARL/PEARL TWIN: 4-button or 2-button transmitters (922.5 MHz)
- TELECODY+ / ENTRAPIN+: Wireless keypads for secure coded entry
- SOMCOM2: External receiver for cross-brand compatibility
- SOMTOUCH: Wireless wall button for up to 2 operators
