Mini Warehouse Garage Door Spring

SKU:
MWRDSP
Write a Review
atc-product:
TORSION-SPRING
atc-product:
TORSION-SPRING-COMM
atc-product:
CUT-AND-CONED-SPRINGS
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

The four specific items required to purchase the correct replacement Mini Warehouse garage door torsion spring.

#1 Wire Size

#2 Inside Diameter

#3 Length of spring

#4 Wind of spring (Right or left wound)

WIRE SIZE:

A spring’s wire size can be determined by several different tools or techniques. Use of a caliper, micrometer, or wire gauge are common ways to determine a spring’s wire size. If none of these tools are available, simply measure ten coils of wire to the nearest 1/16th of an inch. The spring must be tightly compressed, with no gaps. It’s also a good idea to measure twenty coils as a double check.

INSIDE DIAMETER:

Measure the inside diameter to the nearest 1/16th of an inch.

LENGTH OF SPRING:

Measure spring length with the spring in its unwound state. In the case of a distorted or broken spring, simply count the total number of coils and multiply by the wire size. 120 coils x .250 wire = 30" 120 coils x .375 wire = 45"

RIGHT OR LEFT HAND WOUND:


Please remember the side of the door a spring is located on does not indicate the wind of the spring.

LEFT WOUND SPRING AND RIGHT WOUND SPRING RESPECTIVELY

Mini Warehouse Garage Door Spring for Self Storage Doors - Left Wound and Right Wound Springs
