Action Industries

Air Switch for Treadle Systems, 2-wire, Int./Ext., metal case

SKU:
A2526-00-Z
Write a Review
  • Usually Ships Following Business Day
availability:
available
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

The A2526-00-Z commercial garage door opener pneumatic air switch is an adjustable exterior air switch that can be adjusted to normally-closed or normally-open settings. The waterproof NEMA 4-rated metal enclosure will protect inside components from the elements.

This commercial grade door operator air switch with a 2 million-impulse life cycle will function with pressure levels ranging from 1/4 ounce per square inch to 20 pounds per square inch. This air switch works with up to 300 feet of treadle hose. It's 4 3/8 in. long, 2 5/8 in. wide and 2 7/16 in. deep. Works with treadle hose, gum hose, and coil cords for increased safety on commercial garage doors.

Features:

  • For use with commercial garage door operators

  • NEMA 4-rated

  • Exterior pneumatic air switch

  • Adjust to normally-closed, normally-open

  • Can handle pressure level ranges from 1/4 oz. per sq. inch to 20 lbs. per sq. inch

  • 2-wire metal enclosure protects components from water, weather damage

  • Voltage rating: 6V to 220V, 2 Amps

  • Momentary action only,

  • Works with up to 300 ft. of hose

  • 2 million-impulse life cycle

  • Connects to gum hose, treadle hose, and coil cords for a complete pneumatic reversing edge system
