LiftMaster 6580L Plus – 1 HP Professional Garage Door Opener Kit

Built for professional installers, the 6580L is the Plus-tier step below Premium— but still delivers quiet belt-drive performance with smart monitoring and integrated safety lighting. Action provides this model as a complete kit, including belt-drive rails in 7 ft, 8 ft, and 10 ft options so you can match door height and finish installs in one trip.

Key installer benefits

• Quiet DC belt drive for smooth starts/stops and minimized callbacks in attached garages.
• myQ® Wi-Fi for remote monitoring, alerts, and customer support visibility.
• 360° adjustable camera for live view and video confirmation in the myQ app.
• Dual LED lighting brightens the garage without frequent bulb replacements.
• Battery-backup capable design to keep doors moving during outages (battery kit compatible).
• New Security+® 3.0 radio technology for reliable, long-range, encrypted control.

What’s in the box

• 6580L opener head with integrated camera and LED lighting
• Smart wall control (L957W) and safety sensors
• 3-Button remote control (L993M) with Security+ 3.0
• Action-included belt rails: choose 7 ft, 8 ft, or 10 ft
• Battery backup (485LM)

Ideal use cases

• Residential garages where quiet performance and smart features matter to the homeowner
• Attached garages and multi-door residential projects
• Standard lift residential doors matched to 7/8/10 ft rail lengths

Specifications

• Motor: 1HP, 12V, 53 RPM, automatic thermal protection, permanent lubrication
• Mechanics: Steel chassis, T-Rail and trolley, full reinforced belt drive mechanism (63:1 gear reduction and adjustable door arm)
• Electronic Limits: For easy set up
• Power: 120V AC, 60 Hz, 2.7A current rating, UL listed, 6' power cord (3 prong)
• Speed: 9" per second upward, 6.5" per second downward
• Lighting: 1500 lumens w/ Dual LED
• Dimensions of Opener Head: 10.5" L x 21.7" W x 8.2" H
