Product Description
The LiftMaster LMS24R Fire Rated Red Strobe is an audio-visual signaling device designed for commercial door operator and facility alert applications. Featuring a high-visibility flashing strobe and adjustable audible alarm, this unit provides clear warning indication in entryways, loading areas, and interior commercial environments.
The compact housing features contoured edges for wall or surface mounting and supports simple two-wire installation. Designed for 12VDC or 24VDC operation, the LMS24R can integrate with compatible LiftMaster commercial operators and external power supply systems.
Specifications
- Model: LMS24R
- Application: Audio-visual warning and signaling device
- Voltage compatibility: 12 VDC or 24 VDC/FWR
- Operational voltage range: 8V–17.5V (12V nominal), 16V–33V (24V nominal)
- Strobe flash rate: 1 flash per second
- Strobe brightness: 15 candela @ 12V, 30 candela @ 24V
- Audio alert: Adjustable volume with external rotary control
- Connection type: 2-wire installation
- Housing: Red plastic body with vertical “FIRE” marking
- Mounting: Wall or surface mount
- Use case: Commercial operators, dock doors, entryways, and warning applications
- Compatible with LiftMaster DDO8900W and similar commercial operators
- Requires LiftMaster 100MAPS external power supply for certain operator applications
- Requires on/off or toggle switch for controlled operation
- Dimensions: 5.6" L x 3.46" W x 1.91" D
