Miller Edge Intelligent Radar Sensor for Doors

SKU:
MWAVE
Write a Review
  • Usually Ships 4 to 7 Business Days
Product Type:
Radar Motion Sensor
availability:
available
  • Shipping Cost? For the cost of shipping your item please add the item into the shopping cart. Once the part is in the cart fill out address information in the cart under the Shipping area in the Summary section. Our system will then calculate the shipping fee based on your location and the weight of the product. This is all done before you are asked to provide payment information.

MWave is a fully customizable, hands-free radar motion sensor equipped with dual relays. The intelligent dual relay design differentiates between approaching versus cross-traffic, as well as pedestrian versus vehicular traffic. The MWave is ideal for fast-pace environments and comes pre-configured for a wide range of applications. When paired with the optional MWave Remote Control the device can be programmed from the ground, making setup fast and easy. The MWave increases safety, security, and productivity in applications like high speed doors, high performance doors, first responder facilities, cold storage facilities, auto dealerships, warehouses, and more.

Features:

  • IP67 rating for wet, rain, snow, dust, and debris

  • Swivel mounting bracket for adjusting detection field

  • Ideal for both indoor and outdoor applications

  • Highly visible LED indicators

  • Doppler radar technology

  • Optional MWave remote control for fast and easy programming

  • 3-year warranty

Specs:

  • Technology - Doppler Radar

  • Detection Mode - Radar motion sensor

  • Minimum Detection Speed - 2 inches per second minimum

  • Response Time - <100 milliseconds

  • Output - 2 channel N.O./N.C. (selectable)

  • Output Hold Time - 0.5-300 seconds (adjustable)

  • Operating Temperature - -4°F - +140°F

  • Humidity - Maximum 90% non-condensing

  • Degree of Protection - IP67, NEMA 6

  • Agency Approvals - FCC rules Part 15

  • Enclosure Material - Polycarbonate

  • Color - Black

  • LED Indicators - 2 red/green bi-color LEDs

  • Mounting Height - Minimum 10 ft., Maximum 23 ft.

  • Dimensions with mounting bracket - 5-1/8 W x 2-7/8 H x 5-3/8 D inches

  • Dimensions without mounting bracket - 5-1/8 W x 2-7/8 H x 3-7/8 D inches

  • Weight - 11.5 oz (23 oz. with cable)

  • Detection Zone - 21 W x 29 D ft. at installation height of 16 ft. and inclination angle of 45°, 18 W x 32 D ft. at installation height of 23 ft. and inclination angle of 45°

  • Mounting Angle - -90°/+90° increments

  • Switching voltage - 48 V AC/DC, 1/2 Amp

  • Power Source - 12-36 V DC, 12-28 V AC

  • Max Power Consumption - 1 W
