Swing Door Operator - DC7000 Low Energy ADA Compliant

The ADA-Compliant Low Energy Door System from Door Controls USA, distributed by Action Industries, provides dependable automated access for commercial and public entryways. Designed to meet ADA and ANSI accessibility requirements, this low energy operator supports safe, controlled door operation while maintaining fire and life-safety compliance. Suitable for both new construction and retrofit applications, the system is compatible with butt-hung and center-pivoted doors and integrates with touchless activation devices for hygiene-sensitive environments. Multiple arm styles, door configurations, and finish options allow installers to match a wide range of facility requirements.

Specifications

• Compliant with ADA 1990, ANSI A156.19, and ANSI A117.1 standards
• Maximum single-door width: 3' to 3'6"
• Maximum pair-door width: 5' to 7'
• Maximum door panel weight: 200 lbs per panel
• Power input: 120/220 VAC, 50–60 Hz, single phase
• 15 amp service requirement
• Current draw: 3.15 amps
• Adjustable hold-open time delay from 2 to 30 seconds
• Minimum 5-second opening time compliant with ANSI A156.19
• Compatible with butt-hung and center-pivoted door applications
• Supports touchless activation systems for enhanced accessibility and hygiene
• Available for single, pair, and double egress door configurations
• Arm options include Push, Pull, and Push/Pull for double egress applications
• Available in Left- or Right-hand configurations
• Finish options include Clear Anodized and Dark Bronze Anodized
• Suitable for healthcare, education, hospitality, retail, and other commercial facilities
• Designed for efficient installation in new construction and retrofit projects
